Outdoor LED Billboards

Outdoor Waterproof

Glassless design

Sunlight Readable Image

Ultra-Narrow Bezel

High Brightness

Heat Dissipation

Product Features

Enhanced Visibility and Engagement for Roadside Advertising

One of the primary advantages of outdoor LED billboards over traditional static billboard formats is the ability to display dynamic, animated content that captures motorist and pedestrian attention far more effectively than static imagery. Dynamic content, video, and animated graphics deliver significantly higher recall rates than static advertising, enabling advertisers to communicate more complex messages and achieve greater campaign impact from the same billboard location.

Ultra-High Brightness for Visibility at Roadside Distances

Roadside LED billboards must remain legible at viewing distances of 50 to 500 metres in direct sunlight. onQ's outdoor LED billboards deliver brightness levels up to 10,000 nits, ensuring vivid, legible content in the most challenging outdoor lighting conditions. Automatic brightness adjustment reduces power consumption at night while maintaining full brightness during daylight hours.

IP65 Weatherproof Construction for Long-Term Outdoor Operation

onQ's outdoor LED billboards carry an IP65 weatherproof rating, providing complete protection against dust and water ingress in the full range of Australian weather conditions. The robust enclosure design and high-quality LED components are engineered for long-term outdoor operation, minimising maintenance requirements and maximising the operational life of the billboard asset.

Flexible Advertising Inventory Management via onQ CMS

onQ's outdoor LED billboards integrate with onQ CMS for centralised advertising inventory management. Schedule multiple advertisers across time slots, manage campaign start and end dates, deliver proof-of-play reports to advertisers, and update creative assets remotely without requiring physical access to each billboard location.

Applications for Outdoor LED Billboards

onQ's outdoor LED billboards are deployed by outdoor media companies for roadside digital advertising networks, retailers for large-format exterior brand advertising, property developers for building facade advertising assets, sports stadiums for perimeter advertising and scoreboard applications, shopping centres for exterior tenant and event advertising, and any property owner seeking to monetise their outdoor advertising inventory through digital LED technology.

Real-Time Content Updates

The ability to update content in real-time offers businesses the agility to respond to market trends, news, or unforeseen events promptly. This responsiveness ensures that advertising content remains relevant and engaging, which can lead to increased consumer interest and higher conversion rates.

‍

Strategic Placement and Audience Targeting

Placing LED billboards in high-traffic areas such as highways, city centers, and commercial districts ensures maximum exposure. Coupled with data analytics, businesses can assess the effectiveness of specific locations and times, allowing for strategic planning and optimization of advertising efforts. This targeted approach enhances the likelihood of reaching potential customers, thereby increasing sales opportunities

‍

Gallery

No items found.

Specifications

Pixel Pitch	10mm
Pixel Density (dots/m²)	10,000
LED Encapsulation	SMD3535
Scan Rate	1/2 scan
Module Size	320×320mm
Module Resolution	32×32
Cabinet Size	960×960×100mm
Cabinet Resolution	96×96
Weight per Cabinet	24.5kg
Brightness (cd/m²)	≥6,500 (8,000–10,000)
Max Power Consumption (W/m²)	450
Ave Power Consumption (W/m²)	150
Protection	Front IP67 / Rear IP65
Refresh Rate (Hz)	≥1,920 (3,840 optional)

Pixel Pitch	8mm
Pixel Density (dots/m²)	15,625
LED Encapsulation	SMD3535
Scan Rate	1/4 scan
Module Size	320×320mm
Module Resolution	40×40
Cabinet Size	960×960×100mm
Cabinet Resolution	120×120
Weight per Cabinet	24.5kg
Max Power Consumption (W/m²)	450
Ave Power Consumption (W/m²)	150
Protection	Front IP67 / Rear IP65
Refresh Rate (Hz)	≥1,920 (3,840 optional)

Pixel Pitch	6.6mm
Pixel Density (dots/m²)	22,500
LED Encapsulation	SMD2727
Scan Rate	1/6 scan
Module Size	320×320mm
Module Resolution	48×48
Cabinet Size	960×960×100mm
Cabinet Resolution	144×144
Weight per Cabinet	24.5kg
Max Power Consumption (W/m²)	450
Ave Power Consumption (W/m²)	150
Protection	Front IP67 / Rear IP65
Refresh Rate (Hz)	≥1,920 (3,840 optional)

Pixel Pitch	5.3mm
Pixel Density (dots/m²)	35,156
LED Encapsulation	SMD2727
Scan Rate	1/6 scan
Module Size	320×320mm
Module Resolution	60×60
Cabinet Size	960×960×100mm
Cabinet Resolution	180×180
Weight per Cabinet	24.5kg
Max Power Consumption (W/m²)	500
Ave Power Consumption (W/m²)	175
Protection	Front IP67 / Rear IP65
Refresh Rate (Hz)	≥1,920 (3,840 optional)
